M-PR-CS600-090-T-AN ⏐ CS 100/50 Prime HDD T with Desiccant Dryer
SKU: M-PR-CS600-090-T-AN by MGF Compressors
CS 100/50 Prime HDD, Single Phase, 2.2+2.2kW, 10 Bar, 90Lt Receiver 230v, with Heavy Duty (100% rated pump) and desiccant dryer -40° dew point.
Oil-Free Compressors for Dental, Laboratory, and Clean Air Applications
Introducing our exceptional and versatile range of Oil-Free Compressors, meticulously engineered to meet the highest standards of robustness and efficiency, making them perfect for demanding environments. Designed with precision, our compressors are available in both silenced and standard configurations, and can be equipped with or without advanced membrane dryers.
The silenced version, elegantly housed in a modern acoustic cabinet, offers an impressively low noise output of just 56 dB(A), ensuring a tranquil working atmosphere without compromising on performance.
For those needing the ultimate in air purity, our prime oil-free compressors are fitted with state-of-the-art adsorption air dryers that provide pristine air. They achieve an outstanding filtration level of 0.01 microns and maintain a -40°C dew point at atmospheric pressure, guaranteeing exceptionally clean air delivery.
These superior compressors are ideally suited for the food and medical industries, as well as a wide range of applications where the highest purity of compressed air is essential.
Highlights:
- In cabinet with Dessicant dryer
- Heavy Duty (100% duty) Oil-free tandem pump
- Very quiet, 56 dB(A)
- 2.2 + 2.2 kW Three Phase- 450 l/min @ 5 Bar
- Internally Coated Receiver – 90 Lt
- Using PRIME technology: 100% duty, 56 dB(A), and low temperature output
- Maximum Pressure 10 Bar
- ISO 8573.1 Class 1-2-1 – Particles below 0.1 micron, -40° Degree dew point, and Zero oil trace
- Suitable for laboratory and other applications where oil free and air quality is important
- Integrated membrane dryer guaranteeing a dew point of -40°C at 5 Bar for HTM 2022 & NHS Compliance.
Specification:
| Chairs |
9 |
| CFM @ 5 Bar |
15.8 |
| L/min @ 5 Bar |
450 |
| HP |
6 |
| Kw |
4.4 |
| Bar |
10 |
| PSI |
145 |
| dB(A) |
69 |
| Volt |
230 |
| Receiver Size |
90 Litre |
| Product L x W x H (mm) |
1100 x 680 x 840 |
| KG |
128 |
