CUBE Floor Mounted Air Compressors
Compact fixed-speed direct-drive rotary screw compressors from 4 to 7.5 kW, delivering approximately 16.2 to 37.1 CFM for continuous industrial compressed-air applications.
Compact Industrial CUBE Screw Compressors
The FINI CUBE floor-mounted range is designed for industrial users who need a compact, enclosed rotary screw compressor without an integral receiver. The current floor-mounted range on this page includes three 415V models, covering 4 kW, 5.5 kW and 7.5 kW duties.
The range uses a gearless coaxial direct-drive arrangement, transferring motor power directly to the air-end while avoiding belt-drive transmission losses and reducing the number of drive components requiring routine maintenance.
Shop CUBE Floor Mounted Compressors
Choose the model by required airflow and power. Prices, stock and purchasing information remain available on the individual live product pages.
FINI CUBE 410Floor Mounted Screw Compressor
Fini CUBE 410 (415V)
Compact floor-mounted rotary screw compressor for lower industrial air demand.
FINI CUBE 5.510Floor Mounted Screw Compressor
Fini CUBE 5.510 (415V)
Mid-range CUBE model for workshops and production environments with greater continuous demand.
FINI CUBE 7.510Floor Mounted Screw Compressor
Fini CUBE 7.510 (415V)
Highest-output model in the current floor-mounted CUBE range for heavier continuous air demand.
CUBE Floor Mounted Comparison
| Model | Power | Airflow | Supply | Best For |
|---|---|---|---|---|
| CUBE 410 | 4 kW | 16.2 CFM | 415V | Smaller workshops and lower continuous air demand |
| CUBE 5.510 | 5.5 kW | 24.9 CFM | 415V | General industrial and workshop air demand |
| CUBE 7.510 | 7.5 kW | 37.1 CFM | 415V | Higher continuous production demand |
Why Choose a Floor-Mounted CUBE?
How to Choose the Right CUBE Model
Start With Airflow
Size the compressor against the combined CFM demand of the tools, machines and processes that may run at the same time. Allow a sensible margin for pressure loss and future demand.
Check Available Power
The current CUBE floor-mounted models on this page are 415V three-phase machines, so confirm the electrical supply before ordering.
Confirm Working Pressure
Compressor selection should be based on the required pressure at the point of use, not airflow alone.
Decide Where Air Will Be Stored
These are floor-mounted compressors without an integral receiver. A suitable receiver may be required elsewhere in the system depending on the installation.
Consider Air Quality
If the application requires dry or filtered compressed air, specify the dryer and filtration separately or consider a CUBE configuration with integrated dryer.
Use the Selector if Unsure
The Tanair Compressor Selector can help narrow the wider compressor range by airflow, pressure, voltage, type and configuration.
CUBE Floor Mounted FAQs
What models are available on this page?
The current floor-mounted CUBE range includes the 4 kW CUBE 410, 5.5 kW CUBE 5.510 and 7.5 kW CUBE 7.510.
How much airflow does the range provide?
The current three models cover approximately 16.2 CFM, 24.9 CFM and 37.1 CFM.
Do these compressors include an air receiver?
No. This page is specifically for the floor-mounted CUBE configuration. Receiver-mounted versions are available elsewhere in the CUBE range.
Is a dryer included?
No. These are the standard floor-mounted models without an integrated refrigerated dryer. Separate dryer-equipped CUBE configurations are also available.
What is the benefit of direct drive?
The gearless coaxial arrangement transfers motor power directly to the air-end and removes the need for a conventional belt-drive transmission.
Can Compressed Air Systems UK help size the compressor?
Yes. Provide the required airflow, working pressure, available power and application details and the team can help compare suitable options.
Need Help Choosing a CUBE Compressor?
Tell us your required CFM, pressure, electrical supply and whether you need a receiver or dryer, and we can help identify the most suitable CUBE configuration.
